Victron Orion-Tr Smart 12/12-30A Isolated DC-DC Charger
Victron Orion-Tr Smart 12/12-30A Isolated DC-DC Charger
Couldn't load pickup availability
Victron Orion-Tr Smart 12/12-30A Isolated DC-DC Charger
Charge your 12V auxiliary battery safely and efficiently from your vehicle's alternator with the Victron Orion-Tr Smart 12/12-30A Isolated DC-DC Charger. Featuring built-in Bluetooth, fully programmable charging profiles, adaptive multi-stage charging, and automatic engine-running detection, it's an ideal solution for camper vans, RVs, overland vehicles, boats, emergency vehicles, and commercial service trucks.
Unlike simple voltage boosters, the Orion-Tr Smart delivers a true multi-stage charging profile designed to maximize battery life while ensuring your lithium or lead-acid batteries receive the correct charging voltage. Integrated Bluetooth allows setup and monitoring directly from your smartphone using the free VictronConnect app.
Automatic engine detection eliminates the need for an ignition trigger in most installations, while galvanic isolation helps prevent unwanted ground loops in marine and specialty vehicle applications.
Why You'll Love It
- 30A DC-DC charger for 12V battery systems
- Built-in Bluetooth monitoring and programming
- Fully programmable charging voltages
- Compatible with LiFePO₄ and lead-acid batteries
- Galvanically isolated input and output
- Adaptive 3-stage charging algorithm
- Automatic engine-running detection
- Unlimited parallel operation for higher charging currents
- Remote ON/OFF input
- Backed by Victron's 5-Year Warranty
Camper vans • RVs • Boats • Overland vehicles • Service trucks • Emergency vehicles • Mobile workshops • Off-grid battery charging
Technical Specifications
| Victron Part Number | ORI121236120 |
| Input Voltage | 12V DC |
| Output Voltage | 12V DC |
| Maximum Charge Current | 30A |
| Maximum Output Power | 360W |
| Battery Compatibility | Lithium (LiFePO₄), AGM, Gel & Flooded Lead Acid |
| Isolation | Galvanically Isolated |
| Charging Algorithm | Adaptive 3-Stage (Bulk / Absorption / Float) |
| Bluetooth | Built-in (VictronConnect) |
| Remote On/Off | Yes |
| Parallel Operation | Unlimited Units |
| Ingress Rating | IP43 (Terminals Facing Down) |
| Operating Temperature | -20°C to +55°C |
| Connection Type | Screw-Actuated Cage Clamp Terminals |
| Warranty | 5 Years |
Always install appropriately sized DC fuses as close as practical to both the starter battery and auxiliary battery. Correct cable sizing is essential to minimize voltage drop and ensure the charger can deliver its full 30A output.
